BM-Moto & Snow

Full-width rear ramp, wheel chocks on rails, heated gear lockers so nothing goes home wet, and an insulated package for programs that run into winter.

DWG. BM-MOTO-&-SNOW · GENERAL ARRANGEMENTRamp door · 7,000 lb GVWR · 20 ft · 3–4 machines
RAMP DOOR HEATED LOCKERS FUEL / OIL 20' 0" CHOCKS ON E-TRACK RAIL 4× MACHINE BAY
20' 0"Length
3–4 machinesCapacity
6 daysIn our shop
$12,900Starting price
// For programs that run past November

Ramp door, chocks on rails,
and lockers that dry your gear.

Karting is what we know best, but the same shop, the same aluminum and the same a week or so apply to motocross, road racing and snowmobile programs. What changes is the floor plan: a full-width spring-assisted ramp instead of a barn door, chocks that slide on E-track rails rather than fixed stands, and lockers that are heated rather than just ventilated.

The heated lockers are the part people underestimate. Gear that goes home wet on Sunday is gear that is still damp on Friday. Four hundred watts of low-temperature heat and a through-vent solves a problem that no amount of storage volume does.

Best for

Motocross, road racing and snowmobile programs — especially anyone running past November who is tired of wet gear.

// Standard fit-out

What comes
in the box

This is the baseline for the BM-Moto & Snow, not the upgrade list. Everything below is included in the starting price, and everything below can be changed before we cut metal.

Full-width rear rampSpring-assisted, transition flap included
Wheel chocks on E-track railsSlide to any spacing, lock in place
Heated gear lockers400 W low-temp, through-vented
Ski and track floor linerReplaceable wear surface
Fuel and oil cabinetOutboard vented, spill tray
Cold-weather insulation packWalls, roof and floor
Full-length E-trackFloor and both walls
Work bench with viseFold-down, out of the loading path
// Technical data

Numbers

Overall length
20' 0"
Interior height
7' 0"
Interior width
7' 0"
Axles
Tandem 3,500 lb Dexter torsion
Brakes
Electric, all four wheels
GVWR
7,000 lb
Empty weight
~2,500 lb
Frame
Tube steel frame, factory built
Skin
.040" aluminum
Floor
Factory ply + our wear liner
Rear door
Full-width ramp, spring-assisted
Shop time
6 days once the shell arrives

Weights are for the standard fit-out and will move with options. Full material specification is on the build sheet.

// Consider instead

Configure your own

Mixed programs are common: karts in summer, sleds in winter. Tell us the worst-case weekend and we will draw around that rather than around an average.
